Conone 65

Kindakeyboards

Elevating your input

Details

With our Conone Case we want to bring out a case that resembles a sleek and clean design language, therefore we decided to go with a magnetic mounting solution to keep the top and bottom case part together. This will end in a super clean looking and sleek keyboard case. To make sure this case is held together as solid as screw-mounted cases, there will be a total of 5 magnetic mounting points.


The plates will be screwed into the bottom part using 8 screws. The plate is shaped so that a pleasurable amount of flex can be delivered to our Typers.


The Conone 65 case can easily be taken apart because of the magnetic mounting system. The fact that the plate, pcb and switches can be taken out as a whole by unscrewing the 8 screws that hold the plate to the bottom case part will also deliver you a more pleasant building experience.


The case is tilted at a 5 degree angle and milled out of 6061 aluminum. Switches, which are not included in the kit, will need to be soldered into the PCB. The PCB will connect to your device using its USB-C port, a cable for this will not be included either.


Conone 65 Plates

There will be 4 different plate layouts available, all of them do support split left shift and split backspace. Available options:


  • ANSI 6,25u bottom row
  • ANSI 7u bottom row
  • ISO 6,25u bottom row
  • ISO 7u bottom row



All of the options above will be available in a variety of materials to go with your prefered typing style:


  • Aluminum
  • Brass
  • Copper

PCB

Spec Summary

  • 65%
  • Case material: 6061 Aluminum
  • Typing angle: 5 degrees
  • USB-C connector
  • solder in PCB
  • 4 rubber feet
  • 1,5 mm thick plate
  • Mounting method:
    • Case: Magnetic mounting
    • Plate: Screw mounting

Conone 65 By Kindakeyboards

Color options

Conone 65 Gallery
